W-122/W-122P（Active）

W-122 is a two-way all-weather line array sound reinforcement system with exquisite appearance, compact structure, high sound pressure and high fidelity. *W-122 is equipped with our latest DSP switching mode amplifier module, which can be controlled online. *W-122 can be installed in a variety of combinations. which can be flexibly and conveniently used in all type of applications. *The W-122 cabinet is finished with high-grade black polyurethane paint, which is waterproof and super wear-resistant. The hanging hardware and front grille have undergone tensile strength tests and salt spray tests, making the speaker system suitable for all-weather applications. * W-122 is a bass reflex line array loudspeaker composed of a 4-inch neodymium tweeter and two 12-inch neodymium woofer. The cabinet is made of birch-wood, with a compact structure layout, symmetrical LF speakers, tweeters center.It is also equipped with a magnetic suspension system, which is safe and quick to install. * Applications:            auditorium           Stadium           club           mobile performance

Product number:

Category: W SERIES
BACK

Back to list

Inquire Now
info@cvraudio.com

隐藏域元素占位

  • Product Description
  • Parameter
  • Drawing
  • Connection Diagram
  • Accessories
    • W-122 is a two-way all-weather line array sound reinforcement system with exquisite appearance, compact structure, high sound pressure and high fidelity.
    •
    • *W-122 is equipped with our latest DSP switching mode amplifier module, which can be controlled online.
    •
    • *W-122 can be installed in a variety of combinations. which can be flexibly and conveniently used in all type of applications.
    •
    • *The W-122 cabinet is finished with high-grade black polyurethane paint, which is waterproof and super wear-resistant. The hanging hardware and front grille have undergone tensile strength tests and salt spray tests, making the speaker system suitable for all-weather applications.
    •
    • * W-122 is a bass reflex line array loudspeaker composed of a 4-inch neodymium tweeter and two 12-inch neodymium woofer.
    • The cabinet is made of birch-wood, with a compact structure layout, symmetrical LF speakers, tweeters center.
    • It is also equipped with a magnetic suspension system, which is safe and quick to install.
    •
    • * Applications:

               auditorium

               Stadium

               club

               mobile performance

  • TECHNICAL PARAMETERS
    ModelW-122&W-122P（Active）
    TypeTwo-way line array system
    Frequency Response55Hz-20KHz±3dB
    Power handlingLF 1000W(RMS)4000W(PEAK)
    HF 120W(RMS)480W(PEAK)
    SensitivityLF 108dB(1W@1M)
    HF 110dB(1W@1M)
    Max SPLLF 138dB(PEAK)
    HF 140dB(PEAK)
    DriversLF 2×12"(310mm) neodymium woofer 75mm(3in)coil
    HF 1×4" neodymium compression driver with 100mm titanium diaphragm
    Nominal impedanceLF 8 ohm
    HF 8 ohm
    Coverage120°H×15°V
    ConnectionsLF 1(+)1(-) HF 2(+)2(-)
    Connectors2×NL4MP speakon
    PHYSICAL PARAMETERS
    Finishpolyurea coatings
    Enclosure MaterialBirch Plywood
    CrossoverLF  55Hz-800Hz    HF 800Hz-20KHz
    Dimensions800×355×550mm(W×H×D)
    Packing Dimensions875×455×620mm(W×H×D)0.246cbm
    Net weight42.5kg (W-122) /47.5kg(W-122P)
    Gross weight52kg (W-122) /57 kg(W-122P)
    POWER AMPLIFIER PARAMETERS
    Amplifier typeSwitching mode amplifier,class D circuit
    Power Output(RMS)2X1200W/8ohm
    Weight5kg
    ConfigurationThe amp moduie is built inside W-122P
